压电盘

压电盘
产品描述 规格 下载 报价/订购
  • Piezo material matched to the application
  • Full-surface contact electrodes
  • Can be delivered within two weeks
  • Larger quantities available direct from stock

由铁电软压电陶瓷材料(PIC255)制成的压电陶瓷元件

适用于传感器技术、促动器技术和空气耦合式超声领域中的应用。

径向振荡耦合因子kp:0.62

厚度方向振荡耦合因子kt:0.47

由铁电硬压电陶瓷材料(PIC181)制成的压电陶瓷元件。

适用于大功率超声和声纳领域中的应用。

径向振荡耦合因子kp:0.56

厚度方向振荡耦合因子kt:0.46

可能的修改

尺寸灵活、可选择

压电陶瓷材料

接触

极性

电气连接

组装技术

特殊环境条件

可按需提供定制设计或不同规格。

规格

数据表

压电陶瓷部件数据表

版本/日期
2018-03-15
版本/日期
2018-03-15
版本/日期
2017-09-20
文件语言
pdf - 644 KB
pdf - 648 KB
pdf - 645 KB

下载

数据表

数据表

压电陶瓷部件数据表

版本/日期
2018-03-15
版本/日期
2018-03-15
版本/日期
2017-09-20
文件语言
pdf - 644 KB
pdf - 648 KB
pdf - 645 KB

文件

文件

用户使用手册A000T0047

压电元件的处理和电接触
版本/日期
2019-02-12
版本/日期
2019-02-12
文件语言
pdf - 718 KB
pdf - 725 KB

Quote / Order

Ask for a free quote on quantities required, prices, and lead times or describe your desired modification. All products available online can be ordered directly

Piezo components made of ferroelectric soft piezo material (PIC255), with silver electrodes

PRYY-0886

Piezoelectric disc, outside diameter (OD) = 2 mm × thickness (TH) = 1 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o2 t1 eAg

000022817

Piezoelectric disc, outside diameter (OD) = 3 mm × thickness (TH) = 0.25 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o3 t0.25 eAg

000023079

Piezoelectric disc, outside diameter (OD) = 3 mm × thickness (TH) = 2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o3 t2 eAg

PRYY+0398

Piezoelectric disc, outside diameter (OD) = 5 mm × thickness (TH) = 0.25 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o5 t0.25 eAg

000023074

Piezoelectric disc, outside diameter (OD) = 5 mm × thickness (TH) = 2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o5 t2 eAg

000053020

Piezoelectric disc, outside diameter (OD) = 6.5 mm × thickness (TH) = 0.25 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o6.5 t0.25 eAg

000053024

Piezoelectric disc, outside diameter (OD) = 6.5 mm × thickness (TH) = 1 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o6.5 t1 eAg

PRYY-1129

Piezoelectric disc, outside diameter (OD) = 8 mm × thickness (TH) = 1 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o8 t1 eAg

000014300

Piezoelectric disc, outside diameter (OD) = 8 mm × thickness (TH) = 2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o8 t2 eAg

PRYY+1119

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 0.2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o10 t0.2 eAg

PRYY+0110

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 0.5 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o10 t0.5 eAg

PRYY+0111

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 1 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o10 t1 eAg

PRYY+0372

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o10 t2 eAg

PRYY+0327

Piezoelectric disc, outside diameter (OD) = 16 mm × thickness (TH) = 0.2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o16 t0.2 eAg

PRYY+0332

Piezoelectric disc, outside diameter (OD) = 16 mm × thickness (TH) = 1 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o16 t1 eAg

PRYY+0333

Piezoelectric disc, outside diameter (OD) = 16 mm × thickness (TH) = 2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o16 t2 eAg

PRYY+0349

Piezoelectric disc, outside diameter (OD) = 20 mm × thickness (TH) = 0.2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o20 t0.2 eAg

PRYY+0170

Piezoelectric disc, outside diameter (OD) = 20 mm × thickness (TH) = 1 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o20 t1 eAg

PRYY+0354

Piezoelectric disc, outside diameter (OD) = 20 mm × thickness (TH) = 2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o20 t2 eAg

000014801

Piezoelectric disc, outside diameter (OD) = 25 mm × thickness (TH) = 0.2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o25 t0.2 eAg

PRYY+0189

Piezoelectric disc, outside diameter (OD) = 25 mm × thickness (TH) = 1 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o25 t1 eAg

PRYY+0190

Piezoelectric disc, outside diameter (OD) = 25 mm × thickness (TH) = 2 mm, piezo material PIC255, electrode Ag screen printed; disc c255 o25 t2 eAg

Piezo components made of ferroelectric hard piezo material (PIC181), with silver electrodes

PRYY-0884

Piezoelectric disc, outside diameter (OD) = 2 mm × thickness (TH) = 1 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o2 t1 eAg

PRYY+0853

Piezoelectric disc, outside diameter (OD) = 3 mm × thickness (TH) = 0.25 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o3 t0.25 eAg

PRYY+0850

Piezoelectric disc, outside diameter (OD) = 3 mm × thickness (TH) = 2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o3 t2 eAg

PRYY+0392

Piezoelectric disc, outside diameter (OD) = 5 mm × thickness (TH) = 0.25 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o5 t0.25 eAg

PRYY+0395

Piezoelectric disc, outside diameter (OD) = 5 mm × thickness (TH) = 2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o5 t2 eAg

000053021

Piezoelectric disc, outside diameter (OD) = 6.5 mm × thickness (TH) = 0.25 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o6.5 t0.25 eAg

000053025

Piezoelectric disc, outside diameter (OD) = 6.5 mm × thickness (TH) = 1 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o6.5 t1 eAg

PRYY-0445

Piezoelectric disc, outside diameter (OD) = 8 mm × thickness (TH) = 1 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o8 t1 eAg

000052797

Piezoelectric disc, outside diameter (OD) = 8 mm × thickness (TH) = 2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o8 t2 eAg

PRYY+1113

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 0.2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o10 t0.2 eAg

PRYY+0107

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 0.5 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o10 t0.5 eAg

PRYY+0442

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 1 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o10 t1 eAg

PRYY+0108

Piezoelectric disc, outside diameter (OD) = 10 mm × thickness (TH) = 2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o10 t2 eAg

PRYY+0321

Piezoelectric disc, outside diameter (OD) = 16 mm × thickness (TH) = 0.2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o16 t0.2 eAg

PRYY+0325

Piezoelectric disc, outside diameter (OD) = 16 mm × thickness (TH) = 1 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o16 t1 eAg

PRYY+0326

Piezoelectric disc, outside diameter (OD) = 16 mm × thickness (TH) = 2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o16 t2 eAg

PRYY+0344

Piezoelectric disc, outside diameter (OD) = 20 mm × thickness (TH) = 0.2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o20 t0.2 eAg

PRYY+0348

Piezoelectric disc, outside diameter (OD) = 20 mm × thickness (TH) = 1 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o20 t1 eAg

PRYY+0168

Piezoelectric disc, outside diameter (OD) = 20 mm × thickness (TH) = 2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o20 t2 eAg

000052809

Piezoelectric disc, outside diameter (OD) = 25 mm × thickness (TH) = 0.2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o25 t0.2 eAg

000052810

Piezoelectric disc, outside diameter (OD) = 25 mm × thickness (TH) = 1 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o25 t1 eAg

PRYY+0187

Piezoelectric disc, outside diameter (OD) = 25 mm × thickness (TH) = 2 mm, piezo material PIC181, electrode Ag screen printed; disc c181 o25 t2 eAg
